PYB10-Q24-S5
Manufacturer:
CUI
Mfr.Part #:
PYB10-Q24-S5
Datasheet:
Description:
DC to DC Converters DIP Through Hole Nominal Input Voltage:9 V to 36 V Min Input Voltage:9 V Max Input Voltage:36 V 82 %
| Parameter | Value |
|---|---|
| Length | 50.8 mm |
| Width | 25.4 mm |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Height | 11.8 mm |
| Packaging | Tube |
| Lead Free | Lead Free |
| RoHS | Compliant |
| Weight | 22 g |
| Features | OVP, SCP |
| Min Input Voltage | 9 V |
| Output Voltage | 5 V |
| Max Power Dissipation | 10 W |
| Max Output Current | 2 A |
| Max Input Voltage | 36 V |
| Number of Outputs | 1 |
| Isolation Voltage | 1 kV |
| Output Power | 10 W |
| Current - Output 1 | 2 A |
| Efficiency | 82 % |
| Voltage - Output 1 | 5 V |
| Nominal Input Voltage | 9 V to 36 V |
| Isolation | Isolated |
| Schedule B | 8542390000 |
| Output Current-Channel 1 | 2 A |
| Output Voltage-Channel 1 | 5 V |
